Opis
| Tip procesora | Intel |
| Podnožje | LGA1700 |
| Čipset | B660 |
| Format ploče | Micro ATX |
| Podržani procesori | 12th generacija |
| Memorija | DDR4 |
| Integrisana grafička karta | Preko procesora |
| Slotovi za proširenje | 1 x PCIe 4.0 x16 Slot (x16 mode) 1 x PCIe 3.0 x16 Slot (x4 mode) 1 x PCIe 3.0 x1 Slot |
| Storage | 4 x SATA III Connector (6Gb/s) : Supports AHCI, RAID 0, 1, 5, 10 & Intel Rapid Storage Technology 1 x M.2 (M Key) Socket (M2_PCIEG4_64G) |
| Mrežna karta | Intel I219V |
| Zvučna karta | ALC897 |
| USB | 6 x USB 3.2 6 x USB 2.0 port |
| Konektori na zadnjoj strani | 2 x WIFI Antenna Port 1 x PS/2 Keyboard/ Mouse Port 1 x HDMI 1 x VGA+DVI Port 4 x USB 3.2 (Gen1) port 2 x USB 2.0 port 1 x LAN port 3 x Audio Jack |
| Interni konektori | 4 x SATA III Connector (6Gb/s) 1 x M.2 (E Key) Socket : Supports 2230 type Wi-Fi & Bluetooth module and Intel CNVi 2 x USB 2.0 Header 1 x USB 3.2 (Gen1) 1 x 8-Pin Power Connector 1 x 24-Pin Power Connector 1 x CPU Fan Connector 1 x CPU water cooling connector (CPU_OPT) 1 x System Fan Connector 1 x Front Panel Header 1 x Front Audio Header 1 x Internal Stereo Speaker Header 1 x Clear CMOS Header 1 x COM Port Header 1 x SPI TPM Header 2 x LED Header (5V) 1 x LED Header (12V) |
